MYJ Series Wide-format Laser Molding Machine
Laser Effect | High Speed |800-1600mm
  • Wide Material Compatibility
  • High-Speed
  • Smooth Operation
  • User-Friendly
Technical Specifications
  • Applications
    BOPP, PVC, PET (with pre-coating layer)
  • Max image length
    540mm
  • Moulding width
    800mm/1200mm/1600mm
  • Max. operating speed
    80m/min
  • Max. roll dia
    Φ600mm
  • Core dia
    Φ76mm (3”)
Product Features

For the moulding production of aluminumed foil, BOPP laser packaging film, laser holographic marking film, metallized transfer gold and silver cardboard, aluminium spraying paper and other products.

  • Molding press to achieve laser effect for stamping foil, laser transfer film, laser hologram label film, etc.

  • Profinet/EtherCAT control system: advaned PLC, servo driver & converter control;

  • User-friendly HMI; Busbar power supply, energy-saving and rellable.

  • Automatic Embossing panel mounting;

  • Cooling system for embossing panel changing;

  • Auto tension control for unwind and wind.

  • Remote diagnosis and maintenance service.
